CK45 Chrome Plated Rod Induction And Hardened (HRC 25–32)

CK45 Chrome Plated Rod Induction and Hardened (HRC 25–32) is a high-performance cylinder rod solution. It offers excellent surface hardness, impact resistance, and wear protection, making it ideal for demanding hydraulic and pneumatic systems.

Brand:
EASTAI
Material:
CK45
Length:
Max. 15m
ID Tolerance:
f7/f8/g6,etc
Packing:
Anti rust oil to be spread on rod surface and each rod to be packed in paper roll and then in wooden case,can be customised according to customer requirements
Roughness:
≤0.2u


Availability:



Inquire

Product Description

CK45 Chrome Plated Rod Induction and Hardened (HRC 25–32) is manufactured from high-grade medium carbon steel and treated by induction hardening. This process hardens the surface to HRC 25–32 while keeping the core tough and ductile. A layer of hard chrome plating (typically 20–30μm thick) is then applied for excellent corrosion and wear resistance.

This hard chrome plated rod is built to perform under high pressure, side loads, and harsh environments. It is commonly used as a cylinder rod in construction machinery, hydraulic presses, and industrial equipment where strength and surface durability are critical.

Key Technical Properties

Property	Specification
Material	CK45 / SAE 1045 Medium Carbon Steel
Heat Treatment	Induction Hardened Surface
Surface Hardness	HRC 25–32
Chrome Layer Thickness	20–30 μm
Surface Roughness	Ra ≤ 0.2 μm
Tensile Strength	≥ 600 MPa
OD Tolerance	ISO f7
Straightness	≤ 0.2 mm/m
Standard Length	Up to 6 meters or customized
Application	Cylinder Rod / Chrome Bar / Shaft Rod

Why Choose CK45 Induction Hardened Chrome Plated Rod?

Optimized Hardness
The HRC 25–32 surface provides outstanding wear resistance while maintaining impact toughness. Ideal for cylinders that experience shock or side load.
Durable Chrome Surface
The hard chrome plated rod finish resists rust, moisture, and abrasion, ensuring longer service life in demanding environments.
Precision Fit
Ground and polished to ISO f7 tolerance and Ra ≤ 0.2 μm, ensuring low-friction interaction with seals and bushings.
Strong Core, Hard Surface
The core remains ductile and strong, while the hardened layer enhances surface strength—perfect for dynamic motion applications.
Versatile Applications
Suitable for use as cylinder rods, guide bars, or linear motion shafts in hydraulic, pneumatic, and mechanical systems.

Applications of CK45 Chrome Bar

Hydraulic and pneumatic cylinder rod assemblies
Construction machinery (e.g., excavators, loaders)
Agricultural equipment and lift cylinders
Injection molding and press machines
Offshore and marine hydraulics
Factory automation and industrial robots

This chrome bar is designed to withstand friction, load, and corrosion in challenging environments without compromising precision.

FAQ

FAQs

What is the main advantage of induction hardened CK45 chrome plated rods?

They offer a tough core with a hardened surface (HRC 25–32), giving excellent resistance to wear and bending stress—ideal for high-load cylinder applications.
How is it different from a standard hard chrome plated rod?

While both have chrome coating, the induction hardened version has improved surface hardness and better fatigue resistance under dynamic loads.
Can this rod be used in marine or corrosive environments?

Yes, the chrome layer provides excellent rust protection, but for extended marine use, pairing with proper sealing and maintenance is recommended.
Is CK45 chrome bar weldable?

Yes, CK45 can be welded, but care must be taken due to the hardened surface. Preheating and post-weld tempering may be required.
What’s the typical lead time and delivery for these cylinder rods?

Standard sizes are often in stock. Custom lengths or special tolerances typically require 7–15 business days depending on volume.
